22000 Series
MIL-PRF-15305 (QPL Approved)

RF Inductor

Marking (on face of case)


(Dash Number)


22558


22xxx

FEATURES

  • Inductance Tolerances: Tighter tolerances available upon request

  • Leads: Tin-lead coated copper wire

  • Welded Internal Connections, Transfer Molded Package

SPECIFICATIONS

  • Weight: 0.5 gram, maximum

  • Operating temperature range: -55°C to 125°C

  • Temperature rise (at 90°C): 35°C

  • Power dissipation: 0.2 watt, maximum

  • Terminal Pull: 5 pounds minimum

  • Shock: Method 213 of MIL-STD-202, test condition I

  • Vibration: Method 204 of MIL-STD-202, test condition D

  • Dielectric Withstanding Voltage: Method 301 of MIL-STD-202, test voltage 700 Vrms minimum

  • Space Application: Available to MIL-STD-981

ELECTRICAL CHARACTERISTICS

MS21422-01

MS21422-02

MS21422-03

MS21422-04

MS21422-05



MS21422-06

MS21422-07

MS21422-08

MS21422-09

MS21422-10



MS21422-11

MS21422-12

MS21422-13

MS21422-14

MS21422-15



MS21422-16

MS21422-17

MS21422-18

MS21422-19

MS21422-20



MS21422-21

MS21422-22

MS21422-23

MS21422-24

MS21422-25

22001

22002

22003

22004

22005



22006

22007

22008

22009

22010



22011

22012

22013

22014

22015



22016

22017

22018

22019

22020



22021

22022

22023

22024

22025

Military

Dash Number

C/ACM

P/N

Inductance

±10% (µH)

25

25

25

25

25



25

25

25

25

25



25

25

7.9

7.9

7.9



7.9

7.9

7.9

7.9

7.9



7.9

7.9

7.9

7.9

7.9

Q Min

SRF Min

(MHz)

DCR Max
(Ω)

Current
Max

(mA)

450

400

350

320

300



280

260

240

220

200



180

160

150

130

120



110

100

90

70

60



50

45

40

37

35

0.04

0.05

0.06

0.07

0.08



0.10

0.11

0.14

0.17

0.22



0.27

0.30

0.35

0.40

0.50



0.70

0.90

1.10

1.30

1.50



1.80

2.00

2.20

2.40

2.60

2200

2000

1800

1600

1500



1400

1300

1200

1100

1000



900

800

750

700

630



530

470

420

390

360



330

310

300

290

280

55

65

60

60

65



65

65

65

65

70



70

70

70

60

60



60

60

60

60

60



60

60

60

60

60



Type

Designation

LT4K496

LT4K497

LT4K498

LT4K499

LT4K500



LT4K501

LT4K502

LT4K503

LT4K504

LT4K505



LT4K506

LT4K507

LT4K508

LT4K509

LT4K510



LT4K511

LT4K512

LT4K513

LT4K514

LT4K515



LT4K516

LT4K517

LT4K518

LT4K519

LT4K520

0.10 ± 10%

0.12 ± 10%

0.15 ± 10%

0.18 ± 10%

0.22 ± 10%



0.27 ± 10%

0.33 ± 10%

0.39 ± 10%

0.47 ± 10%

0.56 ± 10%



0.68 ± 10%

0.82 ± 10%

1.00 ± 5%

1.20 ± 5%

1.50 ± 5%



1.80 ± 5%

2.20 ± 5%

2.70 ± 5%

3.30 ± 5%

3.90 ± 5%



4.70 ± 5%

5.60 ± 5%

6.80 ± 5%

8.20 ± 5%

10.00 ± 5%

Test
Freq

(MHz)
