CMWB Series

Commercial Applications

Wideband RF Transformer

FEATURES

  • Leadless device for minimum footprint

  • Low EMI Radiation

  • Low Thermal Expansion permits mounting on most substrate materials

SPECIFICATIONS

  • Frequency Response: 500 kHz to 350 MHz

  • Power Rating: 250 mW

  • Operating Temperature Range: -55°C to 125°C

  • Dielectric Withstanding Voltage: 300 VAC

  • Welded Connections, Transfer Molded Package

ELECTRICAL CHARACTERISTICS

Configuration

Impedance
Ratio
Pri : Sec

Max

Insertion

Loss @50

MHz (dB)

Part

Number

Max
VSWR

@50 MHz

Min Brandwidth (MHz)

0.5 db

(Ripple)

3 dB Points

SMWB1000 Series

SMWB2000 Series

CMWB1010

CMWB1015

CMWB1020

CMWB1040

CMWB1016

SMWB3000 Series

CMWB2010

CMWB2015

CMWB2020

CMWB2040

CMWB2016

CMWB3010

CMWB3015

CMWB3020

CMWB3040

CMWB3016

1 : 1

1 : 1.5

1 : 1.6

1 : 2

1 : 4

1 : 1

1 : 1.5

1 : 2

1 : 4

1 : 1.6

1 : 1

1 : 1.5

1 : 2

1 : 4

1 : 1.6

0.9

1.7

1.3

1.1

1.5*

0.7

1.5

1.1

0.9

1.2*

0.7

1.5

1.1

0.9

1.2*

1.35

1.65

1.40

1.25

1.95*

1.30

1.60

1.35

1.20

1.70*

1.30

1.60

1.35

1.20

1.70*

12 - 35

3.0 - 85

8.0 - 70

4.0 - 130

7.0 - 100

12 - 25

12 - 35

2.0 - 150

2.0 - 150

2.0 - 100

2.0 - 100

6.0 - 90

6.0 - 90

5.0 - 130

5.0 - 130

1.2 - 350

4.0 - 170

0.9 - 200

1.0 - 250

2.5 - 110

1.0 - 390

3.0 - 200

0.5 - 230

0.8 - 300

2.0 - 140

1.0 - 390

3.0 - 200

0.5 - 230

0.8 - 300

2.0 - 140

*Measured at 15 MHz
