Commercial Applications – C24000 Series

RF Inductor

FEATURES

  • Operating Temperature: -55°C to +125°C

  • Dielectric Withstanding Voltage: 700 Vrms

  • Frequency Range: 1 to 50 MHz

  • Terminal Pull: 5 pounds

  • Overload current: 1.4 times the rated current

SPECIFICATIONS

  • Maximum Dissipation: 1/5-Watt

  • Inductance TC: +20 ppm/°C nominal; +50 ppm/°C max

  • Leads: Tin-lead coasted copper wire

  • Welded Internal Connections, Transfer Molded Package

ELECTRICAL CHARACTERISTICS

C24001

C24002

C24003

C24004

C24005



C24006

C24007

C24008

C24009

C24010



C24011

C24012

C24013

C24014

C24015



C24016

C24017

C24018

C24019

C24020



C24021

C24022

C24023

C24024

C24025

C/ACM

P/N

Inductance

(µH)

2.5

2.5

2.5

2.5

2.5



2.5

2.5

2.5

2.5

2.5



2.5

2.5

2.5

.79

.79



.79

.79

.79

.79

.79



.79

.79

.79

.79

.79

Q Min

SRF Min

(MHz)

DCR Max
(Ω)

Current
Max

(mA)

35

31

27

24

22



20

18

16

14

12



11

10

9.1

8.2

7.3



6.4

5.6

5.0

4.4

3.9



3.5

3.1

2.8

2.5

2.2

1.1

1.3

1.5

1.9

2.3



2.7

3.3

3.9

4.7

5.6



6.8

8.1

9.7

12.0

14.0



17.0

20.0

24.0

19.0

22.0



27.0

32.0

19.0

23.0

27.0

550

500

450

410

380



350

320

290

260

240



220

200

180

160

150



140

130

120

130

120



110

100

130

120

110

75

75

75

80

80



80

80

80

80

80



80

80

80

45

45



45

50

55

55

55



55

55

55

50

50



10 ± 5%

12 ± 5%

15 ± 5%

18 ± 5%

22 ± 5%



27 ± 5%

33 ± 5%

39 ± 5%

47 ± 5%

56 ± 5%



68 ± 5%

82 ± 5%

100 ± 5%

120 ± 5%

150 ± 5%



180 ± 5%

220 ± 5%

270 ± 5%

330 ± 5%

390 ± 5%



470 ± 5%

560 ± 5%

680 ± 5%

820 ± 5%

1000 ± 5%

Test Frequency

(MHz)
